Description
-
-
- Workstation-grade Platform : Intel® Core™ i9/i7/i5/i3 Processor (14th gen, codename : RPL-S Refresh/RPL-S/ADL-S) running with Intel® R680E PCH supports max 65W TDP CPU
- Max 1800W power budget supports dual 900W NVIDIA® or AMD 2-slot full-length graphics card
- Flexible Power Input Design with Software Ignition Control : DC 16V to 50V
- Up to 7 Slot PCIe expansions with PCIe 4.0 x8 and PCIe x4 signals
- 2 Front-access M.2 and 2 2.5″ SSD Tray, multiple 5G/WiFi/4G/LTE/GPRS/UMTS
- 4 DisplayPort up to 4K resolution, USB 3.2 Gen 2×2 Type C with a max speed of 20Gbps data transfer supported, 2 Independent 2.5G LAN with Intel® TSN
- Support remote devices Out-Of-Band management functions powered by Allxon
-
High-performance AI Inference Platform
- Intel® Core™ i9/i7/i5/i3 Processor (14th gen, codename : RPL-S Refresh/RPL-S/ADL-S) running with Intel R680E PCH, max 24-core 65W TDP 5.2GHz CPU supported
- 4 DDR5 Memory, up to 128GB, optional supports ECC
- Supports performance hybrid architecture and advanced AI capabilities for smarter and faster applications
- Intel UHD Graphics 770 supports DirectX 12, OpenGL 4.5, OpenCL 3.0
- Optional delivers outstanding AI computing productivity supporting max 10752 CUDA Cores, 84 RT Cores, and 336 Tensor Cores, delivers 75.6 TFLOPS RT Core performance, and 309.7 TFLOPS Tensor performance
- High-speed data transfer : PCIe 4.0 (16GT/s), USB 3.2 Gen 2×2 Type-C (20G), USB 3.2 Gen 2 (10G), SATA III (6G), 2.5GigE LAN (2.5G), GigE LAN (1G)
Advanced Integration
-
-
- Fully supports 3-slot, 2-slot, single-slot & full-length discrete graphics card
- Intel Deep Learning Boost for accelerated AI performance
- Intel Turbo Boost Technology 2.0 accelerates processor performance on peak loads
- Supports Intel vPro, TPM 2.0, PXE, Wake on LAN for remote control
- Supports TSN and Intel TCC for real-time control
- Fully supports Intel OpenVINO toolkit for AI Computing
- Optional supports remote device Out-Of-Band management functions powered by Allxon
-
Flexible Configuration
-
-
- Flexible product configuration for project requirements
- Max 7 PCIe expansions : PCIe 4.0 x16, PCIe x8, PCIe x4
- PCIe expansions for multiple 10GigE M12 PoE+ LAN, 10GigE PoE+ LAN, 10GigE LAN, 10G SFP+, 2.5GigE PoE+ LAN, 2.5GigE LAN, 100W PoE++, M12 PoE+ LAN, PoE+ LAN, GigE LAN, LAN Switch, USB, or Discrete Graphics
- Max 1800W power budget optional supports levels of full-length discrete graphics, max 10752 CUDA Core Computing
- Multiple compact M.2 Key B, M.2 Key E, M.2 Key M connections for Storage and Expansion
- Flexible Wide Range Power options : DC 16V to 50 Power Input or AC 90V to 240V Power Input
-
Industrial Optimization
-
-
- EN50155 & EN50121-3-2 compliant
- ICE 61373 : Anti-shock, Anti-vibration
- Dual high-reliable Intel 2.5GigE LAN support TSN
- Trusted longevity supports
- Wide range power input facilitates indoor, outdoor, and even in-vehicle operating environments
- 16-mode SW Ignition Power Control benefits for in-vehicle operation
- 32 Isolated DIO, 4 COM RS-232/422/485
- 3 External SIM sockets supports always-on 5G/WiFi/BT/4G/LTE/GPRS/UMTS Wireless Communication
- Remote Power Switch
-
